Rove DL
Not finding what you want here?
Contact your local Kona Dealer.
Are you looking for a smooth ride across mixed terrain? Is fun your main goal? Do you appreciate the ride quality and timeless appeal of steel? Do you want a bike that looks great, rides exceptionally well, and can stay with you for years to come? If you're searching for a capable gravel bike that balances performance, comfort, and style without breaking the bank, the Rove DL is the one. A proven workhorse for years, it delivers reliable performance whether you're exploring back roads, commuting, heading out for weekend adventures, or loading up for your next bikepacking trip. Could the Rove DL be the bike that checks all your boxes?
SPECS & GEOMETRY
SPECIFICATIONS
| FRAME | Kona Butted Cromoly |
| SIZES | 48, 50, 52, 54, 56, 58 |
| REAR SHOCK | n/a |
| FORK | Kona Cromoly |
| CRANKSET | Shimano CUES 6030 40t / Length 48 165mm / 50 170mm / 52-54 172.5mm / 56-58 175mm |
| BOTTOM BRACKET | Shimano BSA 68mm |
| PEDALS | n/a |
| CHAIN | Shimano CUES LG500 |
| CASSETTE | Shimano CUES LG400 11-50t 11spd |
| CHAINGUIDE | n/a |
| FRONT DERAILLEUR | n/a |
| REAR DERAILLEUR | Shimano CUES 6000 |
| SHIFTERS | Shimano CUES 6030 |
| BRAKE CALIPERS | Shimano CUES 6030 |
| FRONT BRAKE ROTOR | Shimano RT54 180mm 6B |
| REAR BRAKE ROTOR | Shimano RT54 180mm 6B |
| BRAKE LEVERS | Shimano CUES 6030 |
| HEADSET | FSA Orbit No.1/No.10 EC34/ZS44 |
| HANDLEBAR | Kona Gravel Dropbar 31.8mm / Width 48 40cm / 50 42cm / 52 44cm / 54 46cm / 56-58 48cm |
| STEM | Kona 31.8mm / Rise 6º / Length 48 60mm / 50 70mm / 52-54 80mm / 56-58 90mm |
| SEATPOST | Kona w/Offset 27.2mm / 48-52 350mm / 54-58 375mm |
| SEAT CLAMP | Kona Clamp 31.8mm |
| GRIPS | Kona Cork Tape |
| SADDLE | WTB Volt Medium SL |
| FRONT HUB | Shimano 105 12x100mm |
| REAR HUB | Shimano 105 12x142mm HG |
| SPOKES | Stainless 2.0mm Black |
| RIMS | WTB ST i23 TCS 2.0 |
| FRONT TIRE | Maxxis Rambler 48-52 650x47mm / 54-58 700x40mm |
| REAR TIRE | Maxxis Rambler 48-52 650x47mm / 54-58 700x40mm |
| PAINT COLOR | Gloss Metallic Charcoal w/ Orange & Black Decals |
GEOMETRY
| Size | 48 | 50 | 52 | 54 | 56 | 58 | |
| 1 | ST Length | 480 | 500 | 520 | 540 | 560 | 580 |
| 2 | TT Length | 515 | 531 | 546 | 562 | 578 | 598 |
| 3 | Reach | 372 | 378 | 383 | 388 | 392 | 400 |
| 4 | Stack | 532 | 551 | 570 | 588 | 607 | 626 |
| 5 | Standover | 737 | 755 | 777 | 807 | 828 | 847 |
| 6 | HT Angle | 70.5 | 70.5 | 71.0 | 71.0 | 71.5 | 71.5 |
| 7 | HT Length | 90 | 110 | 130 | 150 | 170 | 190 |
| 8 | ST Angle | 75.0 | 74.5 | 74.0 | 73.5 | 73.0 | 72.5 |
| 9 | CS Length | 435 | 435 | 435 | 435 | 435 | 435 |
| 10 | BB Drop | 74 | 74 | 72 | 72 | 70 | 70 |
| 11 | BB Height | 270 | 270 | 272 | 284 | 286 | 286 |
| 12 | Wheelbase | 1016 | 1029 | 1036 | 1048 | 1054 | 1068 |
| 13 | Front Center | 592 | 604 | 612 | 623 | 628 | 643 |
| 14 | Fork Length | 410 | 410 | 410 | 410 | 410 | 410 |
| 15 | Fork Offset | 50 | 50 | 50 | 50 | 50 | 50 |
Sizing & Selection
Choosing the right bike size is essential for comfort, performance, and the best riding experience. To help you select the correct size:
- Check Our Sizing and Fit Chart: Use the chart below to determine the size range that works best for your height and riding style.
- Get Personalized Recommendations: Not sure which size to choose? Fill out our Sizing Form, and Kona staff will provide suggestions to help you find the perfect fit.
GRAVEL / DROP BAR / URBAN
| Height/Inches | Height/Metric | Inseam/Inches | Inseam/Metric | Rove | Libre | Sutra/Ouroboros | Dews | CoCo |
|---|---|---|---|---|---|---|---|---|
| 4'10"-5'1" | 147-155cm | 24”-27” | 61-69cm | 48cm | 50cm | 48cm | N/A | XS |
| 5'0"-5'3" | 152-160cm | 26"-29" | 66-74cm | 48-50cm | 50cm | 48-50cm | Small | Small |
| 5'2"-5'7" | 157-170cm | 27"-30" | 69-76cm | 48-52cm | 50-52cm | 48-52cm | Small, Medium | Small, Medium |
| 5'6"-5'10" | 168-178cm | 29"-31" | 74-79cm | 52-54cm | 52-54cm | 52-54cm | Medium | Medium |
| 5'9"-6'0" | 175-183cm | 30"-33" | 76-84cm | 52-56cm | 54-56cm | 54-56cm | Medium, Large | Medium, Large |
| 5'11"-6'2" | 180-188cm | 32"-35" | 81-89cm | 54-58cm | 54-58cm | 54-58cm | Large, XL | Large |
| 6'1"-6'5" | 185-196cm | 33"-36" | 84-91cm | 56-58cm | 58cm | 56-58cm | XL | N/A |
MTB FULL SUSPENSION / HARDTAIL / SPLICE
| Height/Inches | Height/Metric | Inseam/Inches | Inseam/Metric | MTB/XC Trail/Fat | All Mountain/Enduro | Splice |
|---|---|---|---|---|---|---|
| 4'10"-5'1" | 147-155cm | 24”-27” | 61-69cm | XS | XS | Small |
| 5'0"-5'3" | 152-160cm | 26"-29" | 66-74cm | Small | Small | Small |
| 5'2"-5'7" | 157-170cm | 27"-30" | 69-76cm | Small, Medium | Small, Medium | Small, Medium |
| 5'6"-5'10" | 168-178cm | 29"-31" | 74-79cm | Medium | Medium | Medium |
| 5'9"-6'0" | 175-183cm | 30"-33" | 76-84cm | Medium, Large | Medium, Large | Medium, Large |
| 5'11"-6'2" | 180-188cm | 32"-35" | 81-89cm | Large, XL | Large, XL | Large, XL |
| 6'1"-6'5" | 185-196cm | 33"-36" | 84-91cm | Large, XL | Large, XL | Large, XL |
